Getting Started
Power Supply Cable
Connect the power cable to the board and plug the other end into a power
outlet. To power up the board, place the power switch (S10) in the ON
position. When power is supplied to the board, the LED (D13)
illuminates.
After the board powers up, the on-board flash memory, which ships
pre-programmed with the factory design, automatically configures the
Stratix II GX device. The CONF DONE LED (D14) illuminates, signaling
that the Stratix II GX device is configured.
1
If the board does not power up after the power cable is
connected, make sure that the power switch (S10) is in the ON
position.
Setting the Clock
Circuit Switches
Set the DIP switch S8 and slide switch S9 per the instructions listed in
Table 2–2 .
Table 2–2. Setting the Clock Circuit Switches, Note (1)
S8-1, S8-2, and PCIe Clk
S8-3, S8-4 and PCIe Clk
S8-5 and PCIe Clk
S8-6 and Basic Clk
S8-1
Low
High
Low
High
S8-2
Low
Low
High
Low
PCIe Clk
(U5)
25 MHz
100 MHz
125 MHz
200 MHz
S8-3
Low
High
Low
High
S8-4
Low
Low
High
High
PCIe Clk
(U5)
±25%
-0.5 %
-0.75 %
No
S8-5
High
Low
—
—
PCIe Clk
(U5)
Enable
Disable
—
—
S8-6
High
Low
—
—
Basic Clk
(U8)
Enable
Disable
—
—
spread
Note to Table 2–2 :
(1)
When using the clock speed DIP switch bank (S8), set switches 1-5, 7, and 8 in the closed position, and switch 6 in
the open position.
1
To use the on board oscillator, the slide switch (S9) needs to be in the OSC
position. However, to use the SMA connectors J5 and J6, the slide switch
needs to be in the SMA position. The I/O standard of the pattern generator
should be set to LVPECL, LVDS, LVHSTL, SSTL, or the HCSL level.
Altera Corporation
Getting Started User Guide 2–9
June 2006
Transceiver Signal Integrity Development Kit, Stratix II GX Edition
